Name: Coal Oil Fired Industrial Steam Boilers High Pressure Steam Boilers
Brand: KANGWEI
Price: 1 USD

Place of Origin : china

Brand Name : KANGWEI

Certification : ABS,BV,NK

Model Number : According to the design and technical demand

MOQ : 1SET

Packaging Details : CONTAINER ,WOODEN CASE

Delivery Time : Negotiate

Payment Terms : T/T, L/C

Supply Ability : depend on the designing capacity

Fuel : oil/gas/Coal

Price : negotiated

Contact Now

Coal / Oil Fired Industrial Steam Boilers , High Pressure Steam Boilers

1. Applications:

Marine /Industry

2. FACTORY ASSURANCE:

One year parts warranty
Spare parts available at ex-factory price
Different voltage available
100% tested before delivery
Minimum installation on site, electrical hook up, water pipe connection, steam pipe connection and drain only
Skid-mounted complete system available
Complete system in container available

3. SPECIFICATIONS:

Model Items		WNS0.5-0.8-Y/Q	WNS0.75-0.8-Y/Q	WNS1-0.8-Y/Q
Boiler horsepower		32 HP	48 HP	63.8 HP
Rated steam output		500 KG/HOUR	750 KG/HOUR	1000 KG/HOUR
Maximum working pressure (manual reset)		<0.8MPa / 116PSI	<0.8MPa / 116PSI	<0.8MPa / 116PSI
Saturated steam temperature		<174°C	<174°C	<174°C
Material of main body		20# carbon steel	20# carbon steel	20# carbon steel
Thickness of main body		12mm	14mm	14mm
Thermal efficiency		>88%	>88%	>88%
Fuel consumption	0# diesel	34kg/h	51kg/h	68kg/h
	Natural gas	40.6Nm3/h	60.9Nm3/h	81.2Nm3/h
	LPG	27.3kg/h	41kg/h	54.6kg/h
Packing dimensions	L	2680mm	2680mm	3982mm
	W	1660mm	1760mm	1917mm
	H	1680mm	1996mm	2090mm

Coal / Oil Fired Industrial Steam Boilers , High Pressure Steam Boilers
